SMT Yamaha YSM10 pick and place machine original used in stock

Products

LCD glass sucher/vacuum suction pen

SMT solder paste mixer/smd counter

SMT NSK LUBE grease/grease gun

SMT Splice tape/smt splice tools

SMT Yamaha YSM10 pick and place machine original used in stock

Price:	$60,000.00 - $1,100,000.00/pieces
Standard Packaging:	YSM10 pick and place machine
Supply Capacity:	1000000 Piece/Pieces per Month YSM10 pick and place machine

Detail Information

Product Description

Detail Information

Place of Origin

Japan

Brand Name

SMD Chip Mounter Machine

Model Number

YSM10 pick and place machine

Condition:

Weight (KG):

Showroom Location:

Video Outgoing-inspection:

Provided

Machinery Test Report:

Provided

Marketing Type:

Hot Product 2019

Warranty Of Core Components:

1 Year

Core Components:

Warranty:

1 Year

Product Name:

YSM10 Pick And Place Machine

Skype:

Sensenhenhao

Whatsapp/wechat:

+8613424013606

Model Number::

YSM20 SMDCHIPMOUNTER

Applicable Components::

Nts: 0402~5050

Usage::

SMD LED SMT

Application::

SMT Assembly Production Line

Film Materials::

Privacy Material

Power Supply::

AC220V 50Hz / AC110V

Lead Time:

7-30days

Port:

Shenzhen

Product Description

SMT Yamaha YSM10 pick and place machine original used in stock

whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322

WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .

Also can support some original parts of machine repair.

YSM10 pick and place machine Specification:

Basic Specifications

Model	YSM10
Applicable PCB Dimensions	L 510 x W 460mm - L 50 x W 50mm * Option: Up to L610 mm available
Mounting Capacity (The Company's optimum conditions)	HM Head (10 Nozzle) Spec.	46,000CPH
	HM5 Head (5 Nozzle) Spec.	31,000CPH
Mounting Accuracy	In the Company's optimum conditions (standard material used for evaluation) ±0.035 mm (±0.025 mm) Cpk1.0 (3)
Applicable Components	03015- W 55mm x L 100mm(divided recognition for over W 45mm), H: 15mm or less *Multi camera requirement (optional) for components over 6.5mm in height, or over 12mm square in size
Number of Component Types	Setting Plate	Max 96 types (8 mm width tape feeder conversion)
	Tray	15 types (sATS15 equipment, Max, JEDEC)
Power Supply	3-phase AC 200/208/220/240/380/400/416 V ±10% 50/60 Hz
Air Supply	0.45 MPa or more, clean and dry state
External Dimensions (excluding protrusions)	L 1,254 x W 1,440 x H 1,445 mm
Weight	1,270kg

YSM10 pick and place machine picture show

SMT Yamaha YSM10 pick and place machine original used in stock 2

SMT Yamaha YSM10 pick and place machine original used in stock 6

SMT Yamaha YSM10 pick and place machine original used in stock 7
