HANWHA PICK AND PLACE MACHINE DECAN S2 SMT chip mounter machine

Hanwha placement machine DECAN S2

1 Enhance the convenience of equipment software management

2 The equipment is equipped with optimized software, which can realize simple program creation/editing

3 Provide various operation information through large LCD screen

4 Highly convenient high-precision electric feeder

5 Calibration Free & Maintenance Free Electric Feeder

6 The single feeder with integrated structure of Reel Bank improves work convenience

7 Through the automatic arrangement function of the suction position of the components between the feeders, the actual production capacity can be increased

8 Through automatic feeding, the work volume can be reduced by half (SMART FEEDER)

9 The industry's first realization of automatic feeding and automatic receiving functions

The manual feeder preparation and receiving operations are changed to automatic methods, which greatly reduces the operation time

Achieve zero consumption of consumables for receiving materials

Hanwha placement machine DECAN S2

1 Speed: 92000CPH

2 Accuracy: CHIP 28um (03015), IC 25um

3 Mountable components (mm): Chip 03015 ~ 5 axis: 12-h10 10 axis: 6-h10

Number of 4 shafts: 10 x 2 Head

5 Fly Camera FOV: 20.5mm

6 PCB size: 50 x 40 ~ 510 x 460mm

Max. 740 x 460 mm (1,200 x 460 mm)

7 Material station: 120ea

8 Equipment weight: 1,800kg

9 Equipment size (mm): 1,430(L) x 1,740(D) x 1,485(H)

10 Power supply: 3 phase AC 200/208/220/240/380/415V ±10%;

50/60Hz; Max. 5.0 Kva
Hanwha DECAN S2
Advanced Chip shooter
1 Speed : 92,000 CPH (Optimum)
2 Structure : 2 Gantry x 10 Spindles/Head
3 Accuracy : ±28μm Cpk≥1.0 (03015 Chip)
                    ±25μm Cpk≥1.0 (IC)
4 Parts Size : 03015~55mm (H15mm)
5 PCB Size : L510xW460mm (Standard)
                    L1,200xW460mm (Option)
6 Wide Part Handling Capability
7 Various PCB Transfer Systems
8 Verified Production History Management Solution
