SAKI AOI machine SAKI BF-planet-X SAKI BF-planet-XII 2D AOI

Products

LCD glass sucher/vacuum suction pen

SMT solder paste mixer/smd counter

SMT NSK LUBE grease/grease gun

SMT Splice tape/smt splice tools

SAKI AOI machine SAKI BF-planet-X SAKI BF-planet-XII 2D AOI

Price:	$1,500.00 - $15,000.00/pieces
Standard Packaging:	SAKI BF-planet-X packing with vacuum wooden case
Supply Capacity:	1000000 Piece/Pieces per Month SAKI BF-planet-X

Detail Information

Product Description

Detail Information

Place of Origin

Japan

Brand Name

SAKI AOI MACHINE

Model Number

SAKI BF-planet-X

Condition:

Weight (KG):

Showroom Location:

Video Outgoing-inspection:

Provided

Machinery Test Report:

Provided

Marketing Type:

Ordinary Product

Warranty Of Core Components:

1 Year

Core Components:

Warranty:

1 Year

Product Name:

SAKI BF-planet-X

Skype:

Sensenhenhao

Whatsapp/wechat:

+8613424013606

Board Size::

50*50 - 250*330mm

Board Warp::

+/-2mm, 79mils

Camera::

Line Color CCD Camera

Board Thickness::

0.6 - 2.5mm

Resolution::

Lighting::

LED Lighting System

Power Consumption::

400VA

Port:

Shenzhen

Product Description

SAKI AOI machine SAKI BF-planet-X SAKI BF-planet-XII 2D AOI

whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322

WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .

Also can support some original parts of machine repair.

SAKI AOI machine SAKI BF-planet-X SAKI BF-planet-XII 2D AOI 0

SAKI BF-planet-X Specification:

Model	SAKI 2D AOI BF-Planet-XII
Resolution	10μm
Board Size	50×60 - 250×330mm, 2×2.4 - 10×13in.
Board Thickness	0.6 - 3.2mm, 24 - 126mils
Board Warp	+/-2mm, 79mils
PCB Clearance	Top: 40mm, 1.57in. Bottom: 40mm, 1.57in
Rotated Component Support	Available for 0 - 359°rotation (unit of 1°)
Inspection Categories	Presence/Absence, Misalignment, Tombstone, Reverse, Polarity, Bridge, Foreign material, Absence of solder, Insufficient solder, Lifted lead, Lifted Chip, andFillet defect. Each defect name can be changed freelyby system function.
Tact Time1 2	Approx. 18sec. (250×330mm)
Image Scanning Time*1	Approx. 9sec. (250×330mm)
Camera (Image Processing)	Line color CCD camera
Lighting	LED lighting system
Transfer Conveyor Method	Flat belt transfer
Transfer Conveyor Height	900+/-20mm, 36+/-0.8in
Transfer Conveyor Width Adjustment	Manual
Operating System	Windows XP English Version
Optional System	BF-Editor / BF-RP1 / BF-Monitor / BF-View
Optional	2D Barcode Recognition, Journal Printer, Automatic Transfer Conveyor Width Adjustment
Electric Power Requirement	Single Phase ~100 - 120V / 200 - 240V +/-10%,50/60Hz, 500VA
Air Requirement	0.5MPa, 5L/min (ANR), 73PSI, 0.18CFM
Usage Environment	15°C(59F) - 30°C(86F) / 15 - 80% RH (Non-condensing)
Noise Level	57.5dB
Dimensions W x D x H	600 × 915 × 1270mm, 24 × 36 × 50in
Weight	Approx. 275kg, 607lbs
1 If PCB size is smaller than 250x330mm, Image scannig time will be shorter than this values. 2 Including Image Scanning Time.

SAKI BF-planet-X picture show

SAKI AOI machine SAKI BF-planet-X SAKI BF-planet-XII 2D AOI 1

SAKI AOI machine SAKI BF-planet-X SAKI BF-planet-XII 2D AOI 2

SAKI AOI machine SAKI BF-planet-X SAKI BF-planet-XII 2D AOI 3

SAKI AOI machine SAKI BF-planet-X SAKI BF-planet-XII 2D AOI 14

SAKI AOI machine SAKI BF-planet-X SAKI BF-planet-XII 2D AOI 16

SAKI AOI machine SAKI BF-planet-X SAKI BF-planet-XII 2D AOI 17
