| Type: | Centrifugal Fan | Applicable Industries: | Manufacturing Plant, Food & Beverage Factory, Factory, ESD Ionizing Air Blower |
|---|---|---|---|
| Customized Support: | ESD Ionizing Air Blower | Electric Current Type: | AC |
| Blade Material: | Plastic | Voltage: | 220V/110V |
| Warranty: | Unavailable | After-sales Service Provided: | No After-sales Service |
| Product: | ESD Ionizing Air Blower | Application:: | Air Blower |
| Rated Voltage:: | 220V | Air Flow Chaacteristics:: | 30cm*30cm Area Coverage |
| Rated Power::: | 110V/60Hz Or 220V/50Hz | Current Consumption:: | 0.45A Or 0.9A |
| Power Supply:: | DC24V | Pressure:: | Medium Pressure |
| Discharge Speed:: | ≤3S (450mm Testing Center From The Air Outlet) | Whatsapp/wechat: | +8613424013606 |
| Port: | Shenzhen |
skype:sensenhenhao,whatsapp/wechat:+8613424013606
SL-002 ESD Ionizing air blower
Testing Voltage: 1kV to 100V
Operating Voltage: 110V/60Hz or 220V/50Hz
Temperature: 22°c,
Testing humidity: 75%RH
ESD Ionizing air blower Characters:
Ionizing air blower is a static elimination device which delivers a balanced ion stream to neutralize in a wide and focus area.
ESD Ionizing air blower Detailed technical parameters:
| Operating Voltage | 110V/60Hz or 220V/50Hz |
| Current Consumption | 0.9A or 0.4A |
| Operating Temperature | -10 ~50°c |
| Air Coverage | 40cm x 90cm |
| Ion balance | 0V±10V |
| Size | 600mm(L) x90mm(W)x170mm(H) |
| Air Volume | 80~220CFM |
| Distance | 300mm | 600mm | 900mm | 1200mm |
| Left 300mm | 1.3s | 2.4s | 2.8s | 4.9s |
| Center | 2.8s | 1.7s | 3.2s | 3.6s |
| Right 300mm | 1.2s | 2.1s | 3.0s | 4.5s |
ESD Ionizing air blower Functions:
They are ideally used in industrial environments, such as delicate electronic products, electronic assembly line, medical device manufacturing and assembly lines, printing, packaging, and small part injection molding.
ESD Ionizing air blower picture show :
