Product Details:
Payment & Shipping Terms:
|
| Machine Type: | HIGH PRESSURE CLEANER | Applicable Industries: | Electronic Factory |
|---|---|---|---|
| Condition: | New | Use: | PCBA Cleaning Machine |
| Cleaning Process: | PCBA Cleaning Machine | Cleaning Type: | Industrial Ultrasonic Cleaner |
| Industry Used: | Electronic Industry | Material: | PCBA Cleaning Machine |
| Power: | Pneumatic Stencil Cleaner | Dimension(L*W*H): | L1300 X W1200 X H850(mm) |
| Warranty: | 1 Year | Max. Pressure: | PCBA Cleaner |
| Marketing Type: | PCBA Cleaner | Machinery Test Report: | PCBA Cleaner |
| Video Outgoing-inspection: | PCBA Cleaner | Warranty Of Core Components: | PCBA Cleaner |
| Core Components: | PCBA Cleaner | Key Selling Points: | PCBA Cleaner |
| Weight (KG): | 600 Kg | Product Name: | PCBA Cleaning Machine |
| Power/Air Supply: | AC380V/50A/50HZ,30KW,0.5Mpa | Cleaning Basket Size: | L610 X W560 X H100 (mm) X2 Layers |
| Spray Tank Capacity: | 17L | Concentrate Capacity: | 32L |
| Dilution Capacity: | 60L | Clean Time: | 5~20min |
| Rinse Time: | 1~2min/times | Skype: | Sensenhenhao |
| Whatsapp/wechat: | +8613424013606 | Port: | Shenzhen |
SMT Automatic Ultrasonic Stencil Hole Cleaning Machine Flux Residual PCBA Cleaning Machine Chemical clean machine
skype:sensenhenhao,whastapp/wechat:+8613424013606
PCBA Cleaning Machine Description:
Flux Residual PCBA Cleaning Machine Chemical clean and DI water rinse machine. SME-5600 is a multi-spec and small batch PCBA flux residual cleaning machine for all kinds of PCBA. It is a large size, off-line, PCBA cleaning machine. It can clean PCBA as big as L650*W650mm.
Super cleaning performance. SME-5600L PCBA cleaning machine can clean flux on PCBA, such as: rosin flux, water-soluble flux , non-clean flux ,solder paste and other organic and inorganic contaminations.
Mainly used in military,aviation, aerospace, medical, new energy, automotive electronics industries, especially suitable for small amount, multiple types PCBA cleaning.
SME-5600L PCBA Cleaning Machine features:
1. All kinds of flux and solder balls can be clean: for example, rosin flux, water-soluble flux , non-clean flux ,solder paste.
2. 2-layers bigger cleaning basket: 700mm(L) ×700mm(W) × 200mm(H) x2 layers.
3. All processes are visible through a large observation window.
4 .Easy operation interface, quick setting clean parameters. Different passwords can be set for ooerator and engineers.
5. Standard liquid and DI water fliter.
6.DI water resistivity real time check. Resistivity range is 0~18 MΩ.
7. Compressed air blow off pipes and pumps, save liquid.
8. High standard cleanliness, ionic contamination completely meets the requirement of IIPC-610D I class.
9. Totally SUS304 structure, solide, acid and alkali corrision-proof
SME-5600L PCBA Cleaning Machine spec:
| ITEM | SPEC |
| Cleaning basket size | L700xW700xH200mmx 2layers |
| Diluent liquid tank capacity | 60L |
| Spray liquid tank capacity | 18L |
| Concentrate tank capacity | 30L |
| Cleaning time | 5~20min |
| Rinse time | 1~2 min/times |
| Rinse times | 1~10times |
| Dry time | 10~30min |
| Diluent liquid heat temp | room temp ~60ºC |
| PCB dry time | room temp~99ºC |
| Resistivity range | 0~18MΩ |
| Liquid filter | 0.2um |
| DI water filter | 0.2um |
| Air filter | 10um |
| Vent size | φ76XH50(mm) |
| Power supply | AC380, 3 Phases, 50/60Hz, 30KW |
| Air supply | 0.5Mpa, 400L/Min |
| Machine size | L1400xW1400x2100(mm) |
| Machine weight | 720KG |
PCBA Cleaning Machine picture show:
