HANWHA DECAN F2 smt chip mounter Advanced PCB Chip shooter

Optimizing PCB transportation paths for productivity improvement
Modular Conveyors
>An optimal conveyor model configuration is possible according to production line composition (shuttle ↔ dual) applied with a modular conveyor that is replaceable on site.
>PCB supply time is shortened as a result of high-speed shuttle conveyor operation.

Minimized head path for improved equipment speed
Twin Servo Control
> Ensuring high-speed operation with a linear motor application to the Y axis, and twin servo control High-speed Flying Head
>Minimized head movement path through recognizing parts during transportation following parts installation
>10-spindle head with individually operating Z axes

[HIGH RELIABILITY]
Placement Accuracy: ±40um (0402mm 01005inch)
> Applied with a high-precision linear scale and rigid mechanism
> Provides precision calibration algorithms and diverse automatic calibration functions

[FLEXIBLE LINE SOLUTION]
Provides optimal line solutions through versatility and productivity improvement
DECAN Line
>Optimal line configuration from chips to uniquely-shaped components according to options setup
Equipment capable of responding to large-scale PCBs, which can be remodeled on site
> Standard equipment can be remodeled on site to equipment capable of large-scale PCB handling
- Responsive to a maximum 740 x 460mm PCB
Responsive to uniquely-shaped components (including tray components)
> Responsive to a maximum 42mm IC when the stage vision option is applied

[EASY OPERATION]
Strengthened equipment software operation convenience
>Convenient production and editing of work programs with built-in equipment optimization software
> Provision of a range of work data and information on a large-scale LCD screen
High-precision, convenient electric feeder
> Calibration and maintenance-free electric feeder
> Improved work convenience with a single reel bank mounted feeder
> Improved productivity through the provision of automatic parts pick-up position alignment between feeders
Reduced work load through parts connection automation (smart feeder)
> Automatic loading and splicing capabilities implemented as an industry first
- Significantly reduction in work time through feeder preparation and parts connection operation automation which were previously carried out manually
> Zero consumables costs for parts connection attained
