Product Details:
Payment & Shipping Terms:
|
| Condition: | New | Weight (KG): | 1000 |
|---|---|---|---|
| Showroom Location: | None | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | Hot Product 2019 |
| Warranty Of Core Components: | 1 Year | Core Components: | PLC |
| Warranty: | 1 Year | Product Name: | LED Pick And Place Machine |
| Skype: | Sensenhenhao | Whatsapp/wechat: | +8613424013606 |
| Model Number:: | YSM20 SMDCHIPMOUNTER | Applicable Components:: | Nts: 0402~5050 |
| Usage:: | SMD LED SMT | Application:: | SMT Assembly Production Line |
| Film Materials:: | Privacy Material | Power Supply:: | AC220V 50Hz / AC110V |
| Lead Time: | 7-30days | Port: | Shenzhen |
JUKI JX-350 SMT Placement LED Pick and Place Machine
whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Introduce of JUKI SMT Placement
SMT production line machine high speed JUKI pick and place, JUKI chip shooter, JUKI SMT placement, for PCB assembly line.
Chip: 32,000CPH chip (Laser centering/Optimum); 21,000CPH chip (Laser centering / IPC9850)
From 0603 to 33.5mmsquare components
JUKI laser centering for high speed, high accuracy placement
Improved placement quality
Alternate pick by screw-type nozzles* achieves high-speed placement for large component up to 25 mm diameter.
High-precision placement of diffusion lenses
Capable of up to 1,500 mm long board production, top class board size in industry
Various supply methods
Specification of JUKI SMT Placement
| Model | JUKI JX-350 SMT Placement | |
| Board size | 1time clamping | 650mm×360 |
| 2times clamping | 1,200×360 | |
| 3times clamping* | 1,500×360 | |
| Component height | 6mm/12mm | |
| Component size | 0603(0201) ~ 33.5mm | |
| Placement speed (chip) | Optimum | 32,000CPH |
| IPC9850 | 21,000CPH | |
| Placement accuracy | ±0.05mm(Cpk-1) | |
| Feeder inputs | Front-side fixed mechanical feeder bank(Standard) | Max.40 in case of 8mm tape |
| Front+rear-side fixed mechanical feeder bank*1 | Max.80 | |
| Front+rear-side fixed electrical feeder bank*1 | Max.160*2 | |
*1 This function is supported with an option.
*2 When using 8mm tape(on a Electric double tape feeder)
Successful Experience:
Meraif's Customer In 35 Countries Around the World
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
5. We Can Solve Any Question About SMT
LED Pick and Place Machine picture show
