SMT GKG GD450+ automatic vision solder paste printer stencil printer machine screen printer machine

Products

LCD glass sucher/vacuum suction pen

SMT solder paste mixer/smd counter

SMT NSK LUBE grease/grease gun

SMT Splice tape/smt splice tools

SMT GKG GD450+ automatic vision solder paste printer stencil printer machine screen printer machine

Price:	$60,000.00 - $1,000,000.00/pieces
Standard Packaging:	SMT GKG GD450+
Supply Capacity:	1000000 Piece/Pieces per Month SMT GKG GD450+

Detail Information

Product Description

Detail Information

Place of Origin

Japan

Brand Name

Auto Paste Printer machine

Model Number

SMT GKG GD450+

Condition:

Weight (KG):

Showroom Location:

Video Outgoing-inspection:

Provided

Machinery Test Report:

Provided

Marketing Type:

Hot Product 2019

Warranty Of Core Components:

1 Year

Core Components:

Warranty:

1 Year

Product Name:

SMT GKG GD450+

Skype:

Sensenhenhao

Whatsapp/wechat:

+8613424013606

Model Number::

YSM20 SMDCHIPMOUNTER

Applicable Components::

Nts: 0402~5050

Usage::

SMD LED SMT

Application::

SMT Assembly Production Line

Film Materials::

Privacy Material

Power Supply::

AC220V 50Hz / AC110V

Lead Time:

7-30days

Port:

Shenzhen

Product Description

SMT GKG GD450+ automatic vision solder paste printer stencil printer machine screen printer machiner

whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322

SMT GKG GD450+ automatic vision solder paste printer stencil printer machine screen printer machine 0

SMT GKG GD450+ printer :

PCB Parameter
Max PCB size (X x Y)	450mm x 350mm
Min PCB size (Y x X)	50mm x 50mm
PCB Thickness	0.4mm~14mm
Warpage	Max. PCB Diagonal 1%
Max PCB weight	10Kg
PCB margin gap	3 mm(conveyor belt PCB/frame touching width)
Max bottom gap	15mm
Conveyor Speed	1500mm/s(Max)
Converyor height	900±40mm
Conveyor direction	L – R,R – L,L – L,R – R
Conveyor method	Single rail
PCB fixing method	Software adjustable pressure elastic side pressure (options: 1, bottom holistic suction vacuum;2, bottom multi-point area vacuum; 3, edge locking substrate clamping)
PCB support Method	Magnetic thimble,equal high block,vacuum suction cavity(option:Grid-Lok)
Printing Parameter
Printing head	Linear motor type close loop printing head
Stencil frame size	370mm x 470mm~737 mm x 737 mm
Max printing area (X x Y)	450mm x 350mm
scraper type	steel scraper/rubber scraper(45°/55°/60)
scraper length	220mm~500mm
scraper height	65±1mm
scraper thickness	0.25mm Diamond-like carbon coating
Printing method	Single or dual scraper
Mould release length	0.02 mm - 12 mm
Printing	0 ~ 200 mm/s
Printing Pressure	0.5kg -10Kg
Printing length	±250 mm(from center)
Cleaning system
Cleaning method Vacuum Dry Cleaning-Vacuum Wet Cleaning-Dry Cleaning (Programming Control)
Cleaning direction forth-back,Back and forth cleaning (programmed control)
Camera Parameter
Imaging area (FOV)	6.4mm x 4.8mm
Platform adjustment range	X,Y:±7.0mm,θ:±2.0°.
Datum point type	Standard shape reference point (see SMEMA standard), pad/hole
Camera System	Single camera, up/down single imaging vision system, geometric matching positioning
Function Parameter
Repetitive accuracy of image calibration	±10.0um @6 σ,Cp more than 2.0
Printing Repetition Accuracy	±20.0um @6 σ,Cp more than 2.0
Cycle time	Less than 7s
Product changing time	Less than 5 mins
Equipment
Power Supply	AC220V±10%,50/60HZ,15A
Air supply	4~6Kg/cm2, 10.0mm tube
Operation System	Windows XP
Dimension	L(1140mm)x W(1400mm)xH(1480mm)
Weight	1000Kg
Temperature humidity control system(Option)
Temperature Control Range	23±3℃
Humidity Control Range	45~70%RH4
