High quality double cup Rubber Sucker Vacuum glass suction lifter
Hand tools Vacuum suction cups catalogue
Horizontal suction: 100kg
Vertical suction: 85kg
Sucker diameter: 118mm
Sucker material: precision cast aluminum alloy
Rubber material: Butadiene rubber
Sucker color: black (colors can be customized)
Product features: High-strength aluminum alloy die-casting disc body, durable and durable metal baking paint, rubber pad with precision formula made of rubber with strong suction, three-jaw suction 100KG
Hand tools Vacuum suction cups price list
glass suction lifter for stone Precautions
1. Wipe the glass plate and suction pad before use.
2. Do not contact rubber pads with various oils and solvents.
3. When the product is stopped, the suction pad rubber should be relaxed.
4. Do not drop the product with force.
5. The product is a hand tool, can not be used for large machinery such as cranes, cranes, etc., nor can it be used to support the weight of the entire person.
glass suction lifter for stone picture show:
The glass sucker uses a high-strength aluminum alloy die-casting disc body, a durable and durable metal baking paint, and a rubber pad with a precision formula made of rubber with a strong suction power of 150KG, which can be customized by OEM.
Structure and use of glass suction cups: Glass suction cups, also known as glass suction cups, are hand tools that are mainly used to pick up and lift smooth objects such as glass plates. It uses the deformation of the rubber pad mounted on the suction cup to generate a vacuum, and uses the atmospheric pressure to firmly hold the article, so as to achieve the purpose of lifting and moving the article. Professionals take objects such as glass, iron plates, stone or ceramic tiles, car shells with flat, uneven, and non-porous surfaces.
Use method and scope of application: Use a cloth to wipe the rubber pad and the articles to be sucked off. The rubber pad faces the article flat. Press the suction cup firmly against the surface of the article and pull down the alloy handle at the same time. Deformation, at this time you can lift and move the item by hand. After the articles have been moved and lowered, pull the handle to the original position to complete the extraction work.
